Home / Products / Nylon Cable Ties / Nylon Cable Ties- Barb-Lock Type
Nylon Cable Ties

Nylon Cable Ties- Barb-Lock Type

Fengfan's BarbLock

Fengfan is the first company, whose BarbLock Nylon Cable Ties are automatic mass production and obtained a patent.

Fengfan's stock products, for urgent client orders.

Fengfan's self-design machine for massive production.

Fengfan's BarbLock has stable product quality, for meeting the customer requirement.

Fengfan can be the OEM to clients, who have professional distribution channels all of the world.

Technical Information

Materialien: Nylon 66

Material Locking Barb: Stainless Steel Grade 304.

Temperature Range: -40℃to 85℃

Color: Nature or Black

Flammability: UL94  V-2

Other properties: Halogen Free

Product Feature

Stainless steel barb provides consistent performance and reliability and infinite adjustability through entire bundle range.

High Strength and low thread force

A stippled strap body prevents lateral movement on the bundle.

The curved tip is easy to pick up from flat surfaces and allows faster initial threading to speed installation.

High loop Strength exceeds industry standards.

A variety of materials are available for specific applications.

For indoor or outdoor use

Available Special Requirements

Flame retardant(UL94 V-0)

UV resistant, ideal for outdoor use with lots of sunlight.

Heat stabilized(up to +125℃). Ideal for environments with high temperatures.

Ideal for the environment requires low flammability and low smoke, such as public transportation, tunnels, etc.

CONTACT US
  • Nylon Cable Ties- Barb-Lock Type
  • Nylon Cable Ties- Barb-Lock Type
  • Nylon Cable Ties- Barb-Lock Type
  • Nylon Cable Ties- Barb-Lock Type
  • Nylon Cable Ties- Barb-Lock Type
  • Nylon Cable Ties- Barb-Lock Type
PREV：Nylon Cable Ties- Self-Lock TypeNEXT：No next article!
Technical parameter
ltem No. Width Length Thickness Max.Bundle Dia. Min. Bundle Dia. Min. Tensile Strength Hand Tool
mm inch mm inch mm inch mm inch mm inch N lbs
NZQOD-2.4*102 2.4 0.094 102 4.02 0.9 0.035 23 0.91 2 0.079 80 18 LS-519
NZQ0D-2.4*160 2.4 0.094 160 6.3 1.2 0.047 42 1.65 2 0.079 80 18
NZQ0D-2.4*201 2.4 0.094 201 7.91 1.2 0.047 51 2.01 2 0.079 80 18
NZQ0D-3*100 3 0.118 100 3.94 1.2 0.047 22 0.87 2 0.079 80 18
NZQ0D-3.6*155 3.6 0.142 155 6.1 1.1 0.043 35 1.38 3 0.118 178 40
NZQ0D-3.6*203 3.6 0.142 203 7.99 1.1 0.043 51 2.01 3 0.118 178 40
NZQ0D-3.6*287 3.6 0.142 287 11.3 1.3 0.051 80 3.19 3 0.118 178 40
NZQ0D-3.6*368 3.6 0.142 368 14.49 1.3 0.051 104 4.09 3 0.118 178 40
NZQ0D-4*150 4 0.157 150 5.91 1.3 0.051 35 1.38 3 0.118 178 40
NZQ0D-4*200 4 0.157 200 7.87 1.3 0.051 50 1.97 3 0.118 178 40
NZQOD-4.7*186 4.7 0.185 186 7.32 1.15 0.045 45 1.77 3.5 0.138 222 50
NZQ0D-4.7*203 4.7 0.185 203 7.99 1.15 0.045 50 1.97 3.5 0.138 222 50
NZQ0D-4.8*250 4.8 0.189 250 9.84 1.3 0.051 65 2.56 3.5 0.138 222 50
NZQ0D-4.8*305 4.8 0.189 305 12.01 1.25 0.049 82 3.23 3.5 0.138 222 50
NZQ0D-4.8*361 4.8 0.189 361 14.21 1.3 0.051 100 3.94 3.5 0.138 222 50
NZQ0D-4.8*376 4.8 0.189 376 14.8 1.45 0.057 105 4.13 3.5 0.138 222 50
NZQ0D-7*221 7 0.276 221 8.7 1.7 0.067 51 2.01 6 0.236 534 120
NZQ0D-7*300 7 0.276 300 11.81 1.7 0.067 80 3.15 6 0.236 534 120
NZQ0D-7*378 7 0.276 378 14.88 1.7 0.067 102 4.02 6 0.236 534 120
NZQ0D-7*538 7 0.276 538 21.18 1.7 0.067 152 5.98 6 0.236 534 120
NZQ0D-7*620 7 0.276 620 24.41 1.7 0.067 180 7.09 6 0.236 534 120
NZQ0D-7*699 7 0.276 699 27.52 1.7 0.067 203 7.99 6 0.236 534 120
NZQ0D-7*780 7 0.276 780 30.71 1.7 0.067 256 10.08 6 0.236 534 120
NZQ0C-8*240 8 0.315 240 9.45 1.6 0.063 57 2.24 9 0.354 450 100
NZQ0D-8*300 8 0.315 300 11.81 1.7 0.067 77 3.03 9 0.354 534 120
NZQ0D-8*350 8 0.315 350 13.78 1.7 0.067 97 3.82 9 0.354 534 120
NZQ0D-8*400 8 0.315 400 15.75 1.65 0.065 108 4.25 9 0.354 534 120
NZQ0D-8*460 8 0.315 460 18.11 1.7 0.067 127 5 9 0.354 534 120
NZQ0D-10*300 10 0.394 300 11.81 1.6 0.063 77 3.03 14 0.551 550 124
NZQ0D-10*350 10 0.394 350 13.78 1.6 0.063 97 3.82 14 0.551 550 124
NZQ0D-10*400 10 0.394 400 15.75 1.6 0.063 109 4.29 14 0.551 550 124
NZQ0D-10*450 10 0.394 450 17.72 1.6 0.063 124 4.88 14 0.551 550 124
NZQ0D-10*600 10 0.394 600 23.62 1.6 0.063 197 7.76 14 0.551 550 124

- Other lengths available, please contact FENGFAN Customer Service.
- For information on installation tools, refer to Hand Tools pages.
- The recommended maximum continuous loading for 12.7mm Strapsis90N per Strap.
- For the best Results suggested spacing is 35 to 40cm.
