Home / Products / Stainless Steel Cable Ties / Stainless Steel Cable Ties- L Type PVC Coated Ties
Stainless Steel Cable Ties

Stainless Steel Cable Ties- L Type PVC Coated Ties

Technical Information
Material: Stainless Steel Grade 304 or 316
Coating: PVC
Working Temp.: -40℃ to 85℃
Description: Black Strap with Metallic Buckle
Flammability: Fireproof
Other Properties: UV-resistant
Product Feature
PVC coating will reduce the cost, than PPA coating.
Softer and thicker PVC provide additional edge protection.
Prevents corrosion between dissimilar metals.
CONTACT US
  • Stainless Steel Cable Ties- L Type PVC Coated Ties
PREV：Stainless Steel Cable Ties- L Type Polyester Coated TiesNEXT：Stainless Steel Cable Ties- L Type Uncoated Ties
Technical parameter
Item No. Width Length Thickness Max.Bundle Dia. Min. Bundle Dia. Min .Tensile Strength Recommended
InstallationTool
mm inch mm inch mm inch mm inch mm inch N lbs
FZLSJ-9*300 9  0.35  300  11.81  1.0  0.039  60  2.36  12.7  0.5  2000  450  DQH
DOL
LQA
LQA-S
LQD
LQD-S
FZLSJ-9*400 400  15.75  92  3.62
FZLSJ-9*500 500  19.69  124  4.88
FZLSJ-9*600 600  23.62  156  6.14
FZLSJ-9*700 700  27.56  188  7.40
FZLSJ-9*800 800  31.50  220  8.66
FZLSJ-9*1000 1000  39.37  284  11.18
FZLSJ-13*300 13  0.51  300  11.81  1.1  0.043  60  2.36  25.4  3000  675  DQH
DQL
LQA
LQA-S
LQD
LQD-S
FZLSJ-13*400 400  15.75  92  3.62
FZLSJ-13*500 500  19.69  124  4.88
FZLSJ-13*600 600  23.62  156  6.14
FZLSJ-13*700 700  27.56  188  7.40
FZLSJ-13*800 800  31.50  220  8.66
FZLSJ-13*1000 1000  39.37  284  11.18
FZLSJ-16*400 16  0.63  400  15.75  1.1  0.043  92  3.62  25.4  3500  790  DQH
DQL
LQA
LQA-S
LOD
LQD-S
FZLSJ-16*500 500  19.69  124  4.88
FZLSJ-16*600 600  23.62  188  7.40
FZLSJ-16*700 700  27.56  220  8.66
FZLSJ-16*800 800  31.50  251  9.88
FZLSJ-16*900 900  35.43  252  9.92
FZLSJ-16*1000 1000  39.37  284  11.18
FZLSJ-16*1200 1200  47.24  348  13.70
Click to view

Leave your requirements, and we will contact you!

Related products

Self-developed and manufactured

Zhejiang Fengfan Cable Fittings Co.,Ltd., is a private joint-equity enterprise, it was founded on June 16th, 2020, with a registered capital of 10 million CNY. The factory has a construction area of 25,000㎡ and covers an area of 12,000㎡. It is located in Shangyu District, Shaoxing City, Zhejiang Province, The city is near Ningbo Seaport, Hangzhou Airport, and Shanghai Seaport.

The company is committed to making independent research, development, manufacturing, and sales on kinds of cable ties, cable cleats automobile clamps, and so on. It mainly produces kinds of stainless steel cable ties (eg, Uncoated, Epoxy/Polyester coated, PVC coated, PPA coated, PA11 coated ), nylon cable ties, weather-resistant acetal products, stainless steel cable cleats, automotive clamps, and other cable accessories. The products are widely used in Offshore Projects, Shipbuilding, Port Machinery, railways, Automobiles, Power Energy, Aviation, Nuclear Power, Electricity, Telecommunication, and so on. The products aim for a middle-high market position, with independent export rights.
